1000W DE Fixture 110-240v Closed (No Bulb)

  • Model: GTE1000W
  • Bulb: 600W-750W-1000W DE lamps (MH/HPS)
  • Input power: 1200W
  • Input voltage range: 85-264V
  • Input voltage: 120-240V
  • Input current: 10.0A
  • Input frequency: 50/60Hz
  • Maximum output power: 1150W
  • Output frequency: >100KHZ
  • Dimmer: 660—750—825—1000—1150—EXT
  • Leakage current: 2.35mA
  • THD: <8%
  • CF lamp: <1.6
  • Power factor: > 0.98
  • Open circuit voltage: 250Vrms
  • Operating frequency: 100KHZ-160KHZ
  • Ignition voltage: 3.5KV-4KV
  • Ignition interval: 1-2-5-5-5 Min
  • Ignition time: 30MS
  • Inrush current: 30A
  • Input current protection: 15A
  • Isolation resistance: 5MΩ
  • Isolation voltage: 3.5KV
  • Bulb failure detection: yes
  • Lamp power: constant
  • Flickering of the lamp / acoustic resonance: no
  • RF interference: no
  • Max temperature of the box: (Tc) 80 ° C
  • Ambient temperature: -25 to 40 ° C
  • Operating humidity: 20%-95%
  • IP environment required: IP__23
  • Unit weight: 7.0Kg
  • Unit size: 675*322*195mm
