1000W DE Fixture 110-240v

CLOSED (NO BULB)

The ION DE 1000W fixtures are standard for any indoor cultivation facility. These lights provide the perfect amount of light penetration and intensity for ideal growing conditions. DE fixtures produce a more intense light than single-ended lamps, which can be readily directed toward the plants when used in combination with a reflector.

Buy Now

1000W DE Fixture 110-240v Closed (No Bulb)

  • 110-240V
  • Max Current 10A
  • Operates HPS & MH Lamps
  • 3 Year Warranty
  • Dimmable Functions: 660-750-825-1000-1150-EXT
  • 1-10V Control Ready
  • Lamps & NEMA Plug Adapter Sold Separately Unit size: 675*322*195mm
Buy Now
Brochure

1000W DE Fixture 110-240v Closed (No Bulb) Specifications

ModelGTE1000W
Bulb600W-750W-1000W DE lamps (MH/HPS)
Input power1200W
Input voltage range85-264V
Input voltage120-240V
Input Current10.0A
Input frequency50/60Hz
Maximum output power1150W
Output frequency>100KHZ
Dimmer660—750—825—1000—1150—EXT
Leakage current2.35mA
THD<8%
CF Lamp<1.6
Power factor> 0.98
Open circuit voltage250Vrms
Operating frequency100KHZ-160KHZ
Ignition voltage3.5KV-4KV
Ignition Interval1-2-5-5-5 Min
Ignition time30MS
Inrush current30A
Input Current Protection15A
Isolation resistance5MΩ
Isolation voltage3.5KV
Bulb failure detectionYES
Lamp powerConstant
Flickering of the lamp / acoustic resonanceNo
RF interferenceNo
Max temperature of the box(Tc) 80 ° C
Ambient temperature-25 to 40 ° C
Operating humidity20%-95%
IP environment requiredIP__23
Unit weight7.0Kg
Unit size675*322*195mm
